In a solar power generation system, the selection of a Solar Inverter is of crucial importance. The following are some key considerations:
Determine the System Scale and Requirements
Evaluate the Power Generation Capacity
First, it is necessary to clarify the scale of the solar power generation system. Select an inverter with an appropriate power capacity based on the total power of the installed solar panels. Generally, the rated power of the inverter should be slightly greater than the total power of the solar panels to ensure efficient processing of the generated electricity. For example, if the total power of the solar panels is 5kW, an inverter of 5.5kW or 6kW can be chosen. This allows for efficient operation under different light conditions and avoids energy losses due to insufficient power.
Consider whether there are plans to expand the solar panel array in the future. If so, a larger power margin for the inverter should be reserved to avoid the need to replace the inverter when the system is upgraded later, thus saving costs.
Match the Load
Analyze the types and power requirements of the electrical appliances. For a system mainly supplying power to low-power loads such as lighting and small appliances, a small but highly efficient inverter can be selected. However, if it is to supply power to high-power equipment such as air conditioners and electric water heaters, it is necessary to ensure that the inverter can stably output sufficient power and has good overload capacity. Usually, a more powerful inverter with better performance needs to be chosen.
Focus on the Characteristics of Inverter Types
Central Inverter
It is suitable for large-scale solar power plants. Its advantage lies in its relatively low cost. It can centrally process the electricity generated by a large number of solar panels and has high conversion efficiency. For example, in a megawatt-scale solar power station, a central inverter can reduce the unit power generation cost through efficient centralized conversion and management.
However, its disadvantage is that if a fault occurs, it may affect the power generation of the entire photovoltaic array, resulting in a large-scale power outage. Therefore, when selecting a central inverter, it is crucial to focus on its reliability and stability and choose a branded product with a good reputation and mature technology.
String Inverter
It is applicable to small and medium-sized photovoltaic systems, especially rooftop distributed photovoltaic power generation projects. It can independently invert and monitor each string of solar panels. When one group has a problem, it will not affect the normal operation of other strings, improving the reliability of the system. For example, in some rooftop photovoltaic systems of commercial buildings or residential houses, if some panels are shaded or have a fault, the string inverter can ensure that other normal panels continue to generate electricity efficiently.
The string inverter has stronger adaptability in complex light environments and can better optimize the power generation efficiency. When selecting, pay attention to the performance of its maximum power point tracking (MPPT) technology to ensure that it can quickly and accurately track the maximum power point of the panels and increase the power generation.
Micro Inverter
The micro inverter is a small inverter directly installed on each solar panel. It can achieve fine control of the maximum power output of each panel, maximizing the power generation efficiency. Even if individual panels have a fault, are shaded, or age, it will not affect the power generation of other panels. For example, in some small photovoltaic systems with extremely high requirements for power generation efficiency and complex light conditions, the micro inverter can play a unique advantage.
However, its cost is relatively high. When selecting, it is necessary to comprehensively consider the scale of the system, the budget, and the requirements for power generation efficiency. If the budget is sufficient and the pursuit of ultimate power generation efficiency and system reliability, the micro inverter is a good choice.
Examine the Efficiency and Performance of the Inverter
Conversion Efficiency
The conversion efficiency of the inverter directly affects the power generation of the solar power generation system. Select an inverter that can maintain high conversion efficiency under different load conditions. Check the efficiency curve of the inverter to understand its efficiency performance under low load, full load, and different light intensities. Generally, an efficient inverter can achieve a conversion efficiency of more than 95% in the load range of 20% - 100%. The higher the conversion efficiency, the more electrical energy can be effectively utilized.
Pay attention to comprehensive efficiency indicators such as European Efficiency and California Energy Commission Efficiency of the inverter. These indicators comprehensively consider the efficiency performance of the inverter under different working conditions and can better reflect its power generation performance in actual operation.
Maximum Power Point Tracking (MPPT) Function
Advanced MPPT technology enables the inverter to monitor the output voltage and current of the solar panels in real time and automatically adjust the working point to ensure that the panels always work near the maximum power point. Select an inverter with a high-precision MPPT algorithm. The higher the tracking accuracy, the more fully the power generation capacity of the solar panels can be utilized. For example, some excellent inverters can achieve an MPPT tracking accuracy of more than 99%, which can effectively increase the power generation of the system.
Understand the MPPT working range of the inverter to ensure that it can adapt to different types and specifications of solar panels. Some inverters have a narrow MPPT working range and may not be able to fully utilize the performance of some new high-efficiency panels. Therefore, choose a product with a wide working range and strong compatibility.
Protection Functions
The inverter should have comprehensive protection functions such as overcurrent protection, overvoltage protection, undervoltage protection, overheating protection, and short-circuit protection. These protection functions can act in time when the inverter has an abnormal situation to protect the safety of the inverter itself and the entire solar power generation system. For example, when the grid voltage fluctuates too high or too low, the overvoltage protection and undervoltage protection functions can prevent the inverter from being damaged and ensure that the quality of the electricity sent to the grid meets the standards.
Check whether the inverter has passed relevant safety certifications such as UL, CE, and TUV. These certifications are an important guarantee of the safety and reliability of the inverter, and the products that have passed the certifications are more guaranteed in terms of quality and performance.
Consider the Reliability and Lifespan of the Inverter
Brand and Reputation
Choosing a well-known brand of inverter usually can obtain better quality assurance and after-sales service. Well-known brands often have stricter standards and more abundant experience in research and development, production, and quality control, and their products are more reliable. You can learn about the reputation and market share of different brands of inverters by viewing industry reports, user reviews, and consulting professionals.
Some brands that have been deeply involved in the solar industry for many years and have a wide user base, such as Huawei and Sungrow, their inverter products have relatively excellent performance in reliability. However, it is also necessary to make a comprehensive selection based on actual needs and budget, and not rely solely on the brand.
Heat Dissipation Design
Understand the operating temperature range of the inverter and choose a product that can adapt to the climate conditions of the installation area. If the installation area has a high temperature in summer or a low temperature in winter, it is necessary to choose an inverter with a wide operating temperature range to ensure its normal operation in extreme temperature environments.
Warranty Policy
The warranty policy of the inverter is also something to consider when selecting. A longer warranty period usually indicates that the manufacturer has more confidence in the product's quality. At the same time, it also provides users with more protection. Understand the specific content of the warranty, such as whether it includes parts replacement, on-site service, etc., to ensure that you can get timely support when there is a problem with the inverter.
